| S.No. |
Technical specification |
Value |
| 1. |
Impact strength down to 400C |
No breakage |
| 2. |
Notch impact strength |
> 30 kJ/m2 |
| 3. |
Ball impact hardness |
100 N/mm2 |
| 4. |
Tensile strength |
> 40 N/mm2 |
| 5. |
E module |
> 2500 N/mm2 |
| 6. |
Linear Thermal Expansion |
Coefficient 300C to+500C 0.80 x 10-4 K-1 |
| 7. |
Thermal Conductivity |
0.16W/mK |
| 8. |
Specific volume resistance |
10 16 Ω cm |
| 9. |
Relative Permittivity |
3.3 at 50GHz
2.9 at 106 Hz |
| 10. |
Fire behaviour |
Self extinguishing |
| 11. |
Weathering stability RAL GZ 716/1 |
After 8.0GJ/m2 irradiation energy better than authenticity grade 4 of grey scale |
| 12. |
Special Resistance |
Resistance to termites, decay, chemicals e.g. alkalines, acids, salts, salty solutions, seawater, petrol, oil, lime, cement, any kind of emissions Physiological Behaviour and environmental characteristics Inert, Neutral, The weathering stability and the resistance against chemical and decay ensure that there exist no health and environmental risks during handling.
|
| 13. |
Physiological Behaviors and environmental characteristics |
Inert, Neutral, The weathering stability and the resistance against chemical and decay ensure that there exist no health and environmental risk during handling |
| 14. |
Wind resistance |
Up to wind pressure of 2400PA |
| 15. |
Acoustic |
Class 5 |
| 16. |
Water Tightness |
Watertight upto 600PA |
| 17. |
Fire Resistance |
Class |
